LaTeX layer

• Auto-build with auctex-latexmk
• Syntax highlighting
• Auto-completion
• Tags navigation on % with evil-matchit
• Labels, references, citations and index entries management with RefTeX

A number of configuration variables have been exposed via the layer config.el. Sensible defaults have been provided, however they may all be overridden in your .spacemacs.

This layer provides two alternative backends to choose from.

LaTex layer support full-document previews and inline preview (via SPC m p).

To update the preview buffer whenever the compiled PDF file changes, set latex-refresh-preview to t in your ~/.spacemacs:

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-refresh-preview t)))

TexLab also supports more sophisticated previewing setup, which is documented here.

A build command can be specified via the layer variable latex-build-command. This variable can be set to any of the entities in TeX-command-list, including any custom entries you may have added there.

If latexmk is found on your system PATH, LatexMk will be chosen as your latex-build-command, unless if it's not set.

To use the regular AucTeX command, set latex-build-command to LaTeX as shown below.

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-build-command "LaTeX")))

auctex and auctex-latexmk have default rules to determine build command and build options according to the buffer-local variable TeX-engine.

It should be one of the symbol defined in TeX-engine-alise. The default valid symbols are:

• 'default
• 'luatex
• 'omega
• 'xetex

An appropriate TeX-engine is required for high-quality typesetting in certain languages. For convenience, 'xetex is chosen when it's found on PATH and when either chinese or japanese layer is enabled.

You can choose the engine on a per file basis, by setting file-local variable. For example, you can append these code to the end of a .tex file:

%%% Local Variables:
%%% TeX-engine: 'xetex
%%% End:

If you predominantly works with one specific engine, you can set it as a layer variable.

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-build-engine 'xetex)))

More information on TeX engine and languages support can be found in auctex manual page.

To disable auto-fill (which is on by default) set the variable latex-enable-auto-fill to nil.

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-enable-auto-fill nil)))

The variable latex-nofill-env provides the list of environment names where auto-fill-mode will be inhibited. By default it includes:

• "equation"
• "equation*"
• "align"
• "align*"
• "tabular"
• "tabular*"
• "tabu"
• "tabu*"
• "tikzpicture"

Enable folding of text by setting latex-enable-folding to t. Default value is nil.

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-enable-folding t)))

To enable "magic" symbols in latex buffers, set the variable latex-enable-magic to t.

(setq-default dotspacemacs-configuration-layers
              '((latex :variables latex-enable-magic t)))

The precise effect of this feature can be modified by adjusting the following variables:

• magic-latex-enable-block-highlight: show font properties like \large (default t).
• magic-latex-enable-block-align: reflect block alignment such as \center (default nil).
• magic-latex-enable-pretty-symbols: substitute symbols in place of code, e.g. greek letters (default t).
• magic-latex-enable-suscript: show subscripts and superscripts (default t).
• magic-latex-enable-inline-image: show images inline (default nil).

By default, the underlying latex code is echoed in the echo area.

Available only when latex-enable-folding is non nil.
